Nitrogen Protected Nozzle Sintering Furnace

Equipment Application

Nitrogen Protected Nozzle Sintering Furnace is Energy Saving type Industrial Electric Furnace that introduces technology from similar German products. It is specially used in the iron and steel, metallurgy industries, High Temperature firing graphite silicon carbide nozzles. It adopts microcomputer program High Precision temperature control, and the whole Automatic implements the nozzle sintering process curve.

Structure Introduction

Nitrogen Protected Nozzle Sintering Furnace is mainly composed of furnace body shell steel structure assembly, Furnace Lining , insulation layer, heating elements, Stainless Steel vacuum tank, internal insulation Furnace Lid , microcomputer program Automatic temperature control system, etc.

The furnace body is rolled from steel plates into the Pit Furnace shell, and the furnace body shell structure is made by combined dense welding of section steel. Furnace Lining Thermal insulation uses extra-long Ceramic Fiber needle-punched blanket, which is formed by High Pressure module molding, and has the advantages of fast Liter temperature rise, excellent thermal insulation performance, Long Service Life and other advantages. Compared with similar electric furnaces in China, Energy Saving saves more than 30% of electricity.

Equipment The heating element used is corrugated and made of High Temperature high-resistance alloy strip 0Cr27Al7Mo2 with a temperature rating of 1440℃. By adopting advanced international algorithms combined with our factory's unique uniform temperature wiring method, the heating elements are reasonably designed and fully distributed inside Furnace Chamber , so the temperature is uniform from top to bottom when performing the nozzle sintering process.

The vacuum tank is made of imported Superalloy Stainless Steel special plate resistant to 1200℃, and is made into a cylindrical tank by Automatic Automatic coiling machine. The microcomputer program Automatic temperature control cabinet has 8-stage High Precision temperature control, with a temperature control accuracy of ±1℃. It can Automatic execute the nozzle sintering process curve, so that the electric furnace operates according to the High Precision nozzle sintering process curve.
