Equipment Application
GR2 Series Crucible Lead Melting Furnace is Energy Saving type Industrial Furnace , mainly used for lead melting, aluminum melting, lead liquid heat preservation and other purposes, and is matched with quantitative die casting and die casting machines, can be used for manufacturing storage batteries, etc. Welcome to purchase our factory's crucible Lead Melting Furnace .
Technical Parameters
GR2-12-6
Rated Power12
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ245
Height265
Connection MethodY
No-load Heating Time2.5
Melting Capacity100
Weight (Reference)380
GR2-30-6
Rated Power30
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ325
Height375
Connection MethodY
No-load Heating Time2.5
Melting Capacity240
Weight (Reference)580
GR2-60-6
Rated Power60
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ500
Height600
Connection Method△
No-load Heating Time2.5
Melting Capacity1000
Weight (Reference)1740
GR2-100-6
Rated Power100
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ600
Height1000
Connection MethodY
No-load Heating Time2.5
Melting Capacity3000
Weight (Reference)2500
GR2-135-6
Rated Power135
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ800
Height1250
Connection MethodYYY
No-load Heating Time2.5
Melting Capacity6000
Weight (Reference)3500
GR2-180-6
Rated Power180
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ1000
Height1200
Connection MethodYYYY
No-load Heating Time2.5
Melting Capacity10000
Weight (Reference)4000
GR2-270-6
Rated Power270
Rated Voltage380
Frequency50
Phases3
Max Temperature650
Working Temperature650
Chamber Size Diameterφ1200
Height1800
Connection MethodYYYYY
No-load Heating Time2.5
Melting Capacity20000
Weight (Reference)6000
* crucibles of various specifications and sizes for users Lead Melting Furnace .
