Isothermal Quenching Nitrate Salt Furnace

Equipment Application

Hankou Furnace Professionally manufactured Isothermal Quenching Nitrate Salt Furnace is designed and manufactured with introduced foreign high and new technology Industrial Furnace , it uses nitrate molten liquid medium to heat workpieces, Nitrate Salt Furnace heats workpieces, the heating speed is relatively fast, oxidation and decarburization are relatively light, the temperature uniformity is high, it is convenient for Isothermal Quenching heat treatment. It is especially suitable for austenite-bainite wear-resistant materials for railway locomotives, ball mill liners, steel balls, and crusher hammers Isothermal Quenching .

Isothermal Quenching Nitrate Salt Furnace Manufacturer

Structure Introduction

Nitrate Salt Furnace Standard configuration: Isothermal Quenching Nitrate Salt Furnace consists of furnace body, Stainless Steel crucible, dual electric convection stirring mechanism, Stainless Steel quick cooling chamber, Electric Heating Element and microcomputer Automatic temperature control cabinet, can use nitrate salt for multiple processes such as parts Quenching , Tempering heating, Isothermal Quenching cooling.

Furnace body: The furnace body is welded from section steel and steel plates, the furnace surface is made of δ=14mm plate, Nitrate Salt Furnace lining uses composite Furnace Lining fiber heat insulation, making the entire Nitrate Salt Furnace structure Standard Energy Saving Furnace Lining .

Heating element: The heating element of Nitrate Salt Furnace uses High Temperature Electric Heating Element to be placed around Nitrate Salt Furnace .

Crucible: The crucible is made of tightly welded heat-resistant Stainless Steel plates, and has passed our factory's X-ray flaw detection. When used as a Isothermal Quenching salt furnace, four quick-cooling packages made of heat-resistant Stainless Steel are arranged inside the crucible.

Isothermal Quenching Nitrate Salt Furnace

Additional Configuration

An electric reciprocating swing material rack can be installed on the furnace body. The workpiece is placed in the material rack and reciprocates in the nitrate salt solution to achieve the effect of uniform temperature, Isothermal Quenching .

It is additionally equipped with a compressed air Stainless Steel intake pipe, which forms a multi-hole jet pipe at the bottom inside the crucible, enabling the nitrate salt solution to quickly circulate and churn, achieving uniform temperature consistency within the nitrate salt solution.

Matching with the use of Nitrate Salt Furnace Automatic temperature control cabinet, it can enable Quenching workpieces to quickly cool down to the process temperature required by Isothermal Quenching for Automatic constant temperature.
